SYSTEMS ENGINEERING INTERNSHIP · 2024
District Energy Digital Twin
A sanitized overview of process simulation, operator-interface development, and control validation for a multi-building district-energy system.
MY CONTRIBUTIONBuilt DeltaV simulation modules for equipment behavior; designed a four-level DeltaV Live HMI following ISA-101; reviewed control narratives and supported PID tuning and closed-loop validation.
TECHNOLOGIESDeltaV DCS · DeltaV Live · HMI · ISA-101 · PID control · process simulation
ILLUSTRATIVE WORKFLOW · NO PLANT DATA
MODEL PROCESS→SIMULATE→VALIDATE CONTROL→REFINE DESIGN
Issue found before commissioningSimulation surfaced a pump recirculation issue; a variable-speed change was implemented to address it.
Client-identifying information, internal HMI screens, plant-specific data, and control diagrams are omitted.
